Perforated Diffuser (BLFT)
Perforated diffuser designed to sit behind low free area metal ceiling tiles (typically 23% free area), so standard metal tiles can be used across the ceiling. Air is distributed evenly through the perforated tile, giving a consistent ceiling with no obvious visible signs of the diffuser.
292 x 292 mm to 876 x 292 mm (single, double and triple). Made to order.
Need help selecting? Call 01536 519 922
Sizes & item codes
Single
A (mm) | B (mm) | C (mm) | D |
|---|---|---|---|
292 | 292 | 58 | Spigot + 100 mm |
392 | 392 | 58 | Spigot + 100 mm |
592 | 592 | 58 | Spigot + 100 mm |
Double
A (mm) | B (mm) | C (mm) | D |
|---|---|---|---|
584 | 292 | 58 | Spigot + 100 mm |
Triple
A (mm) | B (mm) | C (mm) | D |
|---|---|---|---|
876 | 292 | 58 | Spigot + 100 mm |
Options
Available as single (292 x 292, 392 x 392 or 592 x 592 mm), double (584 x 292 mm) or triple (876 x 292 mm) units. Airflow, throw, pressure and NR data for each size are on the data sheet; contact the sales office for selection guidance. Made to order.
